Square D SQR44104WH 15A 2-Pole Duplex Receptacle – Flush Mount – 125V AC

The Square D SQR44104WH X Series duplex receptacle provides reliable 15 Amp, 125 Volt power with tamper-resistant and weatherproof protection. Designed for residential applications, it features a modern flush-facing design, self-grounding brass contacts, and side wire clamps for quick installation. Its durable construction and safety features make it ideal for indoor and outdoor use.

Voltage and rating

• Current Rating: 15 Amps
• Voltage Rating: 125 Volts AC
• Frequency: 60 Hz

Key Specifications

• Product Type: Duplex Decorator Receptacle
• Outlet Configuration: 2-Pole + Ground (NEMA 5-15R)
• Number of Outlets: 2 (Duplex)
• Safety Features: Tamper Resistant, Weatherproof
• Mounting Mode: Flush mounted by screws
• Grounding: Self-grounding with brass contact
• Product Range: X Series (modern residential wiring devices with flush facing design)

Technical Specifications

• Connections – Terminals:
• Phase and neutral: 4 screw terminals (#14-12 AWG copper), 4 push-in terminations (#14 AWG solid copper)
• Earth: 1 screw terminal copper
• Wire Size: #14–12 AWG copper for screw terminals; #14 AWG solid copper for push-in
• Number of Gangs: 1 gang
• Material: Impact-resistant thermoplastic with metal fixing frame
• Surface Finish: Matte
• Color: White
• Certifications: cULus Listed, UL 498, NEMA 5-15R
• Warranty: 24 months

Product Data

• Manufacturer: Schneider Electric
• Brand: Square D
• Model Number: SQR44104WH
• UPC: 785901542568

• Dimensions:

  • Height: 4.06 in
  • Width: 1.42 in
  • Depth: 1.06 in
  • Weight: 3.4 oz (0.21 lbs)
