GE TEY360 Molded Case Circuit Breaker – 60A – 3-Pole – 277/480V AC – 14kA – Bolt-On – TEY Series

The General Electric (GE) TEY360 is a 60A, 3-pole molded case circuit breaker from the Q-Line TEY Series, designed for compatible GE AE lighting panels and commercial electrical distribution applications.

The TEY360 features thermal-magnetic protection with LI (Long-Time and Instantaneous) trip functions for protection against overloads and short-circuit conditions. It uses a bolt-on mounting connection and is rated for 277/480V AC and 250V DC applications, with a 14kA interrupting capacity at 480V AC.

Specifications

• Manufacturer: General Electric (GE)
• Product Type: Molded Case Circuit Breaker
• Catalog No.: TEY360
• Product Family: Q-Line
• Series: TEY
• Frame Size: 125A / TEY Frame
• Current Rating: 60A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 277/480V AC, 250V DC
• Interrupting Rating: 14kA at 480V AC
• Trip Unit: Thermal-Magnetic
• Protection Functions: LI – Long-Time and Instantaneous
• Mounting Type: Bolt-On
• Connection: Bolt-On
• Terminal Type: Copper/Aluminum Lug Connections
• Actuator: Toggle Handle
• Wire Size: 14–10 AWG
• Temperature Rating: 40°C
• Operating Temperature Range: -13°F to 158°F (-25°C to 70°C)
• Application: Commercial Electrical Distribution and Lighting Panel Circuit Protection
• Panel Compatibility: GE AE Lighting Panels
• Brand: General Electric (GE)
• Authenticity: Genuine General Electric Product

Part Numbers & Identification

• Manufacturer Part Number (MPN): TEY360
• Catalog Number: TEY360
• Product Family: GE Q-Line Circuit Breakers
• Series: TEY
• Brand: General Electric (GE)
• Manufacturer: General Electric
• Product Type: Bolt-On Molded Case Circuit Breaker
• Model: TEY360
• Frame: TEY / 125A Frame
• UPC: 783164181074
• GTIN: 40783164182277
• Breaker Configuration: 3-Pole, 60A
• UPC:783164181074

Compatibility

Designed for use with compatible General Electric Q-Line TEY Series circuit breaker applications, including GE AE lighting panels and other approved commercial distribution equipment.

The TEY360 is a 3-pole, 60A, bolt-on molded case circuit breaker rated for 277/480V AC and 250V DC applications. Its thermal-magnetic LI protection provides long-time overload and instantaneous short-circuit protection.

Always verify the specific panel type, approved breaker configuration, system voltage, interrupting rating, conductor requirements, and manufacturer installation specifications before installation.

Certifications

• UL Listed
• CSA Certified
• Q-Line TEY Series
• 60A Rating
• 3-Pole / 3-Phase
• 277/480V AC Rated
• 250V DC Rated
• 14kA Interrupting Rating at 480V AC
• Thermal-Magnetic Protection
• LI Long-Time and Instantaneous Protection
• Bolt-On Connection
• 40°C Temperature Rating
• Genuine General Electric Product
