GE TEYD3090B Molded Case Circuit Breaker – 90A – 3-Pole / 3-Phase – 480/277V – 25kA @ 480V – Bolt-On – TEYD Series

The GE TEYD3090B is a 90A, 3-pole, 3-phase molded case circuit breaker from the General Electric TEYD Series. It features thermal-magnetic protection with a non-interchangeable trip and Long-Time and Instantaneous (LI) trip functions.

The TEYD3090B is rated for 480/277V and provides a 25kA interrupting rating at 480V with a standard interrupting capacity. It uses a bolt-on connection and is supplied with load-side lug terminals. The breaker is rated for operation at 40°C.

Specifications:

• Manufacturer: General Electric (GE)
• Product Type: Molded Case Circuit Breaker
• Product Family: TEYD
• Series: TEYD
• Type: TEYD
• Catalog No.: TEYD3090B
• Current Rating: 90A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480/277V
• Interrupting Rating: 25kA @ 480V
• Interrupting Capacity: Standard
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting / Connection: Bolt-On
• Terminal Type: Load-Side Lug Terminals
• Temperature Rating: 40°C
• Application: Electrical Distribution and Overcurrent Protection
• Brand: GE

Part Numbers & Identification:

• Manufacturer Part Number (MPN): TEYD3090B
• Catalog Number: TEYD3090B
• Model: TEYD3090B
• Product Family: GE TEYD Circuit Breakers
• Series: TEYD
• Type: TEYD
• Brand: General Electric
• Manufacturer: GE
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 90A
• Trip Configuration: Non-Interchangeable LI
• UPC:783164461824

Compatibility:

Designed for use with compatible GE TEYD Series electrical distribution equipment that accepts TEYD Series bolt-on molded case circuit breakers. The TEYD3090B provides 90A, 3-pole thermal-magnetic overcurrent protection for compatible 480/277V electrical distribution applications.

The breaker uses a bolt-on connection and includes load-side lug terminals. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip requirements, terminal arrangement, temperature rating, and installation specifications before installation.

Certifications:

• TEYD Series
• 90A Rated
• 3-Pole / 3-Phase
• 480/277V Rated
• 25kA @ 480V Interrupting Rating
• Standard Interrupting Capacity
• Thermal-Magnetic Protection
• Non-Interchangeable Trip
• Long-Time and Instantaneous (LI) Trip Functions
• Bolt-On Connection
• Load-Side Lug Terminals
• 40°C Rated
