GE TEYF330 Molded Case Circuit Breaker – 30A – 3-Pole / 3-Phase – 480/277V AC – 18kAIC @ 480V / 65kAIC @ 240V – Bolt-On – TEYF Series

The GE TEYF330 is a 30A, 3-pole, 3-phase molded case circuit breaker from the GE TEYF Series. It is designed for overcurrent protection in compatible commercial and industrial electrical distribution equipment.

The breaker features thermal-magnetic Long-Time and Instantaneous (LI) protection and uses a bolt-on mounting configuration for compatible panelboard installations. It provides interrupting capacities of 18kAIC at 480/277V AC and 65kAIC at 240V AC. The TEYF330 is suitable for compatible lighting panelboards, switchboards, and distribution equipment.

Specifications:

• Manufacturer: General Electric (GE)
• Product Type: Molded Case Circuit Breaker
• Catalog No.: TEYF330
• Product Family: GE TEYF Circuit Breakers
• Series: TEYF
• Frame: TEYF
• Current Rating: 30A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480/277V AC
• Additional System Voltage: 120/240V AC compatible
• Frequency Rating: 50/60Hz
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Trip Type: Non-Interchangeable
• Mounting Type: Bolt-On Panelboard
• Terminal Connection: Lug
• Protection: Overload and Short-Circuit Protection
• Interrupting Rating: 18kAIC @ 480/277V AC; 65kAIC @ 240V AC
• Application: Commercial and Industrial Electrical Distribution
• Brand: GE

Part Numbers & Identification:

• Manufacturer Part Number (MPN): TEYF330
• Catalog Number: TEYF330
• Model: TEYF330
• Product Family: GE TEYF Circuit Breakers
• Series: TEYF
• Frame: TEYF
• Brand: GE
• Manufacturer: General Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 30A
• UPC / GTIN: 783164388503 / 00783164388503

Compatibility:

Designed for use with compatible GE TEYF Series electrical distribution equipment, including compatible GE AE lighting panelboards and similar distribution equipment accepting TEYF Series bolt-on circuit breakers.

The TEYF330 provides 30A, 3-pole thermal-magnetic overcurrent protection and is suitable for compatible 480/277V AC and 120/240V AC systems as specified. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, interrupting rating, trip configuration, terminal requirements, and installation specifications before installation.

Certifications:

• UL Listed / UL 489
• CSA Certified
• IEC Standards Compliance
• TEYF Series
• 30A Rated
• 3-Pole / 3-Phase
• 480/277V AC Rated
• 18kAIC @ 480/277V AC
• 65kAIC @ 240V AC
• Thermal-Magnetic Protection
• Long-Time and Instantaneous (LI) Trip
• Bolt-On Mounting
