GE TEYL3015B Molded Case Circuit Breaker – 20A – 3-Pole – 480/277V – 65kA @ 480V – Bolt-On – TEYL Series

The GE TEYL3015B is a 20A, 3-pole, 3-phase molded case circuit breaker from the General Electric TEYL Series. It is rated for 480/277V and provides a 65kA interrupting rating at 480V.

The breaker features thermal-magnetic protection, a non-interchangeable trip, bolt-on mounting, and load-side lug terminals. It is designed for compatible electrical distribution applications requiring high interrupting capacity.

Specifications:

• Manufacturer: General Electric (GE)
• Product Type: Molded Case Circuit Breaker
• Catalog No.: TEYL3015B
• Product Family: TEYL Series
• Series: TEYL
• Current Rating: 20A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480/277V
• Interrupting Rating: 65kA @ 480V
• Interrupting Capacity: Very High
• Calibration Temperature: 40°C
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Mounting Type: Bolt-On
• Terminal Type: Load-Side Lug Terminals
• Application: Electrical Distribution and Overcurrent Protection
• Brand: GE
• Authenticity: Authentic General Electric Product

Part Numbers & Identification:

• Manufacturer Part Number (MPN): TEYL3015B
• Catalog Number: TEYL3015B
• Model: TEYL3015B
• Product Family: GE TEYL Circuit Breakers
• Series: TEYL
• Brand: General Electric (GE)
• Manufacturer: General Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 20A
• upc:783164462517

Compatibility:

Designed for use with compatible GE TEYL Series electrical distribution equipment that accepts TEYL bolt-on molded case circuit breakers. The TEYL3015B provides 20A, 3-pole, 480/277V thermal-magnetic protection with a 65kA interrupting rating at 480V.

The breaker includes load-side lug terminals and uses a bolt-on mounting configuration. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, terminal arrangement, and installation requirements before installation.

Certifications:

• TEYL Series
• 20A Rated
• 3-Pole / 3-Phase
• 480/277V Rated
• 65kA Interrupting Rating @ 480V
• Very High Interrupting Capacity
• Thermal-Magnetic Protection
• Non-Interchangeable Trip
• Bolt-On Mounting
• Load-Side Lug Terminals
• 40°C Rated
• Genuine General Electric Product
