GE THQB32030ST1 Shunt Trip Circuit Breaker – 30A – 3-Pole – 240V AC – 10kA @ 240V – Bolt-On – THQB Series

The GE THQB32030ST1 is a 30A, 3-pole bolt-on molded case circuit breaker with an integrated shunt trip from the GE THQB Series. It is designed for compatible commercial and industrial electrical distribution systems requiring dependable overcurrent protection and remote tripping capability.

The breaker features thermal-magnetic protection, a common-trip configuration, and a factory-installed shunt trip for remote circuit interruption. It is rated for 240V AC with a 10kA standard interrupting rating at 240V AC.

Specifications:

• Manufacturer: General Electric (GE)
• Brand: GE
• Product Type: Molded Case Circuit Breaker
• Catalog No.: THQB32030ST1
• Series: THQB
• Current Rating: 30A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 240V AC
• Interrupting Rating: 10kA @ 240V AC
• Protection Type: Thermal-Magnetic
• Trip Type: Common Trip
• Trip Functions: Long-Time and Instantaneous (LI)
• Shunt Trip: Factory Installed
• Mounting Type: Bolt-On
• Terminal Type: Load-Side Lug Terminals
• Frequency: 50/60 Hz
• Application: Commercial and Industrial Electrical Distribution
• Remote Tripping: Yes

Part Numbers & Identification:

• Manufacturer Part Number (MPN): THQB32030ST1
• Catalog Number: THQB32030ST1
• Model: THQB32030ST1
• Product Family: GE THQB Circuit Breakers
• Series: THQB
• Brand: GE
• Manufacturer: General Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 30A
• Accessory: Factory-Installed Shunt Trip
• upc:783164034080

Compatibility:

Designed for use with compatible GE THQB Series panelboards and electrical distribution equipment that accepts bolt-on molded case circuit breakers. The THQB32030ST1 provides 30A, 3-pole overcurrent protection and includes an integrated factory-installed shunt trip for remote circuit interruption.

Always verify the specific panelboard or load center model, approved breaker type, system voltage, pole configuration, interrupting rating, terminal arrangement, shunt-trip control voltage, and installation requirements before installation.

Certifications:

• 10kA @ 240V AC Interrupting Rating
• 30A Rated
• 3-Pole / 3-Phase
• 240V AC Rated
• Thermal-Magnetic Protection
• Common Trip
• Long-Time and Instantaneous (LI) Trip
• Factory-Installed Shunt Trip
• Bolt-On Mounting
• Load-Side Lug Terminals
• GE THQB Series
