GE THQC32030WL 35 Amp Molded Case Circuit Breaker – 3 Pole – 240 V – 10 kA@240 V – Feed-Thru – Type THQC

The GE THQC32030WL is a 35 Amp, 3-pole, 3-phase molded case circuit breaker from the GE Type THQC series. It is rated for 240 V with a 10 kA interrupting rating at 240 V and is UL Listed. The breaker uses thermal-magnetic protection with LI (Long-Time and Instantaneous) trip functions and is designed for feed-thru mounting with line and load-side lug terminals.

Specifications

• Manufacturer: General Electric
• Brand: GE
• Product Type: Molded Case Circuit Breaker
• Series: THQC
• Type: THQC
• Catalog Number / MPN: THQC32030WL
• Primary Rating: 35 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 240 V
• Interrupting Rating: 10 kA @ 240 V
• Trip Type: Thermal-Magnetic
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: Feed-Thru
• Terminals: Line & Load-Side Lug Terminals

Part Numbers & Identification

• Manufacturer: General Electric
• Brand: GE
• Catalog Number: THQC32030WL
• Series: THQC
• Type: THQC
• Current Rating: 35 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: Feed-Thru
• Terminals: Line & Load-Side Lug Terminals
• UPC: 783164012729

Compatibility

The GE THQC32030WL is designed for compatible GE Type THQC molded case circuit breaker applications. Verify the specific panelboard, system voltage, mounting configuration, terminal requirements, and breaker compatibility before installation.

Certifications

• UL Listed
