Westinghouse BR120AFCS Molded Case Circuit Breaker – 20A – 1 Pole – 120/240V AC – 10kA – Plug-On – BR Series

The Westinghouse BR120AFCS is a 20A, single-pole molded case circuit breaker from the Type BR Series, designed for residential electrical load centers. It provides combination arc fault circuit interruption (AFCI) protection for compatible 120/240V electrical systems.

The BR120AFCS features a thermal-magnetic trip unit with long-time and instantaneous trip functions, a 10kA interrupting rating, and a plug-on connection for compatible BR load centers. It supports copper and aluminum conductors and is designed for reliable branch circuit protection.

Specifications

• Part Number / MPN: BR120AFCS
• Manufacturer: Westinghouse
• Brand: Cutler Hammer
• Product Type: Molded Case Circuit Breaker
• Category: Circuit Breaker
• Item Subcategory: Molded Case
• Family / Series: BR Series
• Type: BR
• Rated Current: 20A
• Voltage Rating: 120/240V AC
• Phase: 1 Phase
• Poles: 1 Pole
• Interrupting Rating (AIC): 10kA @ 120V
• Connection / Mounting: Plug-On
• Functions: LI – Long-Time and Instantaneous Trip
• Protection: Thermal Magnetic
• Breaker Type: Combination Arc Fault Circuit Interrupter (AFCI)
• Temperature Rating: -13°F to 158°F (-25°C to 70°C)
• Wire Size: AWG 14 to AWG 4, Copper/Aluminum
• Dimensions: 8.75 in × 1 in × 4 in
• UPC: 785901368366
• GTIN: 00782114351130
• Weight: 0.53 lb

Part Numbers & Identification

• MPN / Part Number: BR120AFCS
• Type: BR
• Series: BR Series
• UPC: 785901368366
• GTIN: 00782114351130
• Product Identification: Westinghouse BR120AFCS, 20A, 1-Pole, 120/240V AC, 10kA, Plug-On AFCI Circuit Breaker

Compatibility

The Westinghouse BR120AFCS is designed for use with compatible Type BR load centers requiring a 20A, single-pole, 120/240V AC plug-on AFCI circuit breaker.

It supports copper and aluminum conductors within the specified wire-size range. Always verify the load center model, breaker compatibility, conductor size, and electrical requirements before installation.

Certifications

The provided product information identifies the following certification:

• UL Listed
