Eaton XTCE009B10G 9 Amp IEC Contactor – 3 Pole – 190–220 V AC Coil – 1 NO Auxiliary Contact – XT Series

The Eaton XTCE009B10G is a 9 Amp, 3-pole IEC contactor from the Eaton XT Series, designed for full-voltage non-reversing motor control applications. It features a 190 V AC coil at 50 Hz and a 220 V AC coil at 60 Hz, along with one normally open (NO) auxiliary contact. The contactor has a compact Frame B design, screw terminals, and a 45 mm frame size for compatible motor control assemblies.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: IEC Contactor
• Series: XT
• Catalog Number / MPN: XTCE009B10G
• Primary Rating: 9 Amp
• Poles / Configuration: 3 Pole
• Coil Voltage: 190 V AC at 50 Hz / 220 V AC at 60 Hz
• Frequency: 50–60 Hz
• Auxiliary Contacts: 1 NO
• Frame: B Frame
• Frame Size: 45 mm
• Connection / Terminals: Screw Terminals
• Motor Control Type: Full-Voltage Non-Reversing
• Motor Horsepower Ratings:
  • 0.5 HP at 115 V, 1 Phase
  • 1 HP at 200 V, 3 Phase
  • 1.25 HP at 230 V, 1 Phase / 3 HP at 200 V, 3 Phase
  • 3 HP at 230 V, 3 Phase
  • 5 HP at 460 V, 3 Phase
  • 7.5 HP at 575 V, 3 Phase

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: XTCE009B10G
• Series: XT
• Current Rating: 9 A
• Pole Count: 3 Pole
• Product Type: IEC Contactor
• Auxiliary Contacts: 1 NO
• Frame: B Frame
• Frame Size: 45 mm
• Motor Control Type: Full-Voltage Non-Reversing
• UPC:4015082766887

Compatibility

The Eaton XTCE009B10G is intended for compatible Eaton XT Series motor control assemblies and full-voltage non-reversing motor starter applications.
