Eaton XTCE018C10A Magnetic Contactor – 18A – 3-Pole – 600V – 15HP @ 575V – Screw Terminal – XT Series

The Eaton XTCE018C10A is an 18A, 3-pole, 3-phase magnetic contactor from the XT Series. It is an IEC and UL rated full-voltage, non-reversing contactor designed for motor power control applications.

The contactor includes a 120V, 60Hz coil, one normally open (1NO) auxiliary contact, and screw-terminal connections. It provides motor ratings of 5HP at 230V, 10HP at 460V, and 15HP at 575V, with a maximum voltage rating of 600V.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer
• Product Type: Magnetic Contactor
• Catalog No.: XTCE018C10A
• Product Family: XT Series
• Type: XTCE018C
• Current Rating: 18A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Coil Voltage: 120V
• Coil Frequency: 60Hz
• Contactor Configuration: Full-Voltage Non-Reversing
• Motor Rating: 5HP @ 230V
• Motor Rating: 10HP @ 460V
• Motor Rating: 15HP @ 575V
• Auxiliary Contacts: 1NO
• Connection Type: Screw Terminal
• Application: Motor Power Control
• Standards/Ratings: IEC & UL Rated

Part Numbers & Identification:

• Manufacturer Part Number (MPN): XTCE018C10A
• Catalog Number: XTCE018C10A
• Product Family: Eaton XT Series
• Type: XTCE018C
• Brand: Eaton
• Manufacturer: Eaton / Cutler-Hammer
• Product Type: Magnetic Contactor
• Model: XTCE018C10A
• Contactor Configuration: 3-Pole, 18A
• upc:15082770017

Compatibility:

Designed for use in compatible Eaton XT Series motor power control applications requiring an 18A, 3-pole, 3-phase full-voltage non-reversing contactor. The XTCE018C10A includes a 120V, 60Hz coil, one normally open auxiliary contact, and screw-terminal connections.

Always verify the motor horsepower and voltage requirements, control-circuit voltage and frequency, contactor ratings, auxiliary-contact configuration, and equipment compatibility before installation.

Certifications:

• IEC Rated
• UL Rated
• XT Series
• 18A Rated
• 3-Pole / 3-Phase
• 600V Rated
• Full-Voltage Non-Reversing
• 120V / 60Hz Coil
• 1NO Auxiliary Contact
• 5HP @ 230V
• 10HP @ 460V
• 15HP @ 575V
