Eaton XTCE025C10A Contactor – 25A – 3-Pole – 110/120V AC Coil – 25A – Screw Terminals – XT IEC Series

The Eaton XTCE025C10A is a 25A, three-pole IEC contactor from the Eaton XT Series. It is a full-voltage non-reversing contactor with a Frame C construction and screw terminal connections.

The contactor features a 110V AC coil at 50 Hz and 120V AC coil at 60 Hz, along with a normally open (1NO) auxiliary contact. It is suitable for compatible motor-control applications across a range of horsepower ratings and system voltages.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer
• Product Type: IEC Contactor
• Product Family: XT
• Series: XT IEC
• Catalog No.: XTCE025C10A
• Current Rating: 25A
• Number of Poles: 3-Pole
• Contact Configuration: 1NO Auxiliary Contact
• Coil Voltage: 110V AC @ 50 Hz / 120V AC @ 60 Hz
• Frequency: 50–60 Hz
• Frame: C
• Frame Size: 45 mm
• Terminal Type: Screw Terminals
• Starter Type: Full-Voltage Non-Reversing
• Horsepower Ratings: 2, 3, 5/7.5, 10, 15, 20 HP
• Motor Application: 1/3-Phase
• Application Voltages: 115V, 200V, 230/200V, 230V, 460V, 575V
• Application: Motor Control and Electrical Switching
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): XTCE025C10A
• Catalog Number: XTCE025C10A
• Model: XTCE025C10A
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: IEC Contactor
• Product Family: XT
• Series: XT IEC
• Frame: C
• Frame Size: 45 mm
• Configuration: 3-Pole, 25A
• UPC:015082771298

Compatibility:

Designed for use with compatible Eaton XT Series IEC contactor and motor-control applications. The XTCE025C10A is suitable for full-voltage non-reversing motor-control applications and supports the specified motor horsepower ratings across compatible 115V, 200V, 230/200V, 230V, 460V, and 575V systems.

Always verify the motor horsepower, system voltage, coil voltage, phase configuration, contact arrangement, terminal requirements, and applicable electrical control equipment before installation.

Certifications:

• Specific Certifications: Not specified
