Eaton XTCE050D00A Contactor – 50A – 3-Pole / 3-Phase – 110/120V – 50A – Screw Terminals – XT Series

The Eaton XTCE050D00A is a 50A, three-pole IEC contactor from the Eaton / Cutler-Hammer XT Series. It features a Frame D, 55 mm construction with screw terminals and a full-voltage non-reversing (FVNR) configuration.

The contactor is specified for 110 VAC at 50 Hz and 120 VAC at 60 Hz and provides motor horsepower ratings across several voltage and phase combinations. The available information identifies the contact configuration as 0 normally open (NO) and 0 normally closed (NC).

Specifications:

• Manufacturer: Eaton / Cutler-Hammer
• Product Type: IEC Contactor
• Product Family: XT
• Series: XT
• Catalog No.: XTCE050D00A
• Current Rating: 50A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 110 VAC @ 50 Hz; 120 VAC @ 60 Hz
• Frequency: 50–60 Hz
• Contact Configuration: 0NO-0NC
• Frame Size: D
• Width: 55 mm
• Terminal Type: Screw Terminals
• Starter Configuration: Full-Voltage Non-Reversing (FVNR)
• Motor Horsepower Ratings: 3 HP @ 115V 1/3-Phase; 7.5 HP @ 200V; 10/15 HP @ 230/200V; 20 HP @ 230V; 40 HP @ 460V; 50 HP @ 575V
• Application: Motor Control and Electrical Load Switching
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): XTCE050D00A
• Catalog Number: XTCE050D00A
• Model: XTCE050D00A
• Product Family: Eaton XT IEC Contactors
• Series: XT
• Brand: Eaton
• Manufacturer: Eaton / Cutler-Hammer
• Product Type: IEC Contactor
• Configuration: 3-Pole, 50A
• Frame: D
• UPC:4015082778279

Compatibility:

Designed for compatible Eaton / Cutler-Hammer XT Series motor-control and electrical load-switching applications. The XTCE050D00A is a 50A, 3-pole IEC contactor with screw terminals and a full-voltage non-reversing configuration.

Always verify the specific motor application, system voltage, frequency, required horsepower rating, contact configuration, control requirements, terminal arrangement, and installation specifications before installation.

Certifications:

• XT Series
• 50A Rated
• 3-Pole
• 110 VAC @ 50 Hz
• 120 VAC @ 60 Hz
• 0NO-0NC Contact Configuration
• Frame D
• 55 mm
• Screw Terminals
• Full-Voltage Non-Reversing (FVNR)
• Eaton / Cutler-Hammer IEC Contactor
