Eaton XTCE225H22A Contactor – 225A – 3-Pole – 100/120V AC Coil – 2NO-2NC – Screw Terminals – XT IEC Series

The Eaton XTCE225H22A is a 225A, 3-pole, non-reversing IEC contactor from the Eaton XT Series. It features a 100V AC coil at 50Hz or 120V AC coil at 60Hz, 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts, and a Frame H configuration.

The contactor uses screw terminals and is designed for full-voltage non-reversing (FVNR) applications. The supplied information also identifies horsepower ratings for three-phase applications at 200V, 240V, 480V, and 600V.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer
• Product Type: IEC Contactor
• Product Family: XT
• Series: XT IEC
• Catalog No.: XTCE225H22A
• Current Rating: 225A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Coil Voltage: 100V AC @ 50Hz / 120V AC @ 60Hz
• Frequency: 50–60 Hz
• Auxiliary Contacts: 2NO-2NC
• Frame: H
• Frame Size: 140 mm
• Configuration: Non-Reversing
• Starter Configuration: Full-Voltage Non-Reversing (FVNR)
• Connection Type: Screw Terminals
• Horsepower Ratings: 50, 75, 150, and 200 HP at the specified three-phase voltages
• Application: Motor Control and Electrical Switching
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): XTCE225H22A
• Catalog Number: XTCE225H22A
• Model: XTCE225H22A
• Product Family: Eaton XT Contactors
• Series: XT IEC
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: IEC Contactor
• Configuration: 3-Pole, 225A
• Frame: H
• UPC:401508136324

Compatibility:

Designed for compatible Eaton / Cutler-Hammer XT IEC contactor and motor-control applications requiring a 225A, 3-pole non-reversing contactor. The XTCE225H22A provides a 100/120V AC control coil, 2NO-2NC auxiliary contacts, and screw-terminal connections.

The supplied information identifies horsepower ratings at 200V, 240V, 480V, and 600V three-phase applications. Always verify the exact load type, applicable current and horsepower rating, coil voltage and frequency, auxiliary-contact requirements, control-circuit specifications, terminal arrangement, and installation requirements before installation or replacement.

Certifications:

• No specific certification information provided
